17" Panel PC 6.gen, Projected Capacitiv Touch, 1000Nits til sollys, 9~36VDC forsyning IP66 FRONT, Glat front
Varenummer: IPP17-IX-1000NITS
17" Panel PC uden kan mellem touch og ramme, glidende overgang forhindre snavs blivver liggende.
Kan levere klar til brug med SSD, OS installeret.
Andre størrelser og bestykninger haves kontakt vores salgsafdeling.
IPP17-IX-1000NITS
Produkt information
- Vægt
- 6.25Kg
- Materiale
- Aluminum front bezel/ Aluminum die-casting for back cover IP ratingFront Panel IP66
- CPU
- Onboard Intel 6th Core i3/ i5(option) Processors
- Forsyning
- inputDC 9~36V 1x3-pin DC Power input terminal / 1 x 2-Pin Power Switch
- Driftstemperatur
- Operating temperature(°C)0~50˚C
- Porte
- 1 x DB-9 RS-232/422/485, COM1 (Default RS-232)1 x RS-232 DB-9, COM2
- OS SUPPORT
- Windows 7 64 bit / Windows 8 64 bit / Windows 10 IoT 64 bit
- Hukommelse
- 1 x 260Pin SO-DIMM DDR4 up to 16GB 2133MHz
- Lyd
- 1 x Audio Line Out
- Montering
- Panel Mounting / VESA 100 x 100
- Skærm
- Size17" TFT-LCD Max. resolution1280 x 1024 Max. color16.7M Luminance(cd/m²)350 Viewangle(H°/V°)170/170 Backlight lifetime(hrs)50,000
- Luftfugtighed
- humidity10 to 90%@ 40˚C, non-condensing
- Ethernet
- 2 x GbE LAN RJ-45
- USB
- 2 x USB 3.0 type A
- Dimensioner
- (mm)439 x 348 x 64.8
- Touch
- Projected Capacitive Touch InterfaceUSB Light transmission(%)Over 90% OPTION: RESISTIV TOUCH
- Storage
- HDD/SSD1 x 2.5" SATA HDD bay for SATA3 HDD (Easy Accessible)
- Approval
- CE / FCC, Class A
- mPCIe
- On board expansion bus1 x Internal Mini-PCIe slot full size
17" TFT-LCD Projected Capacitiv Touch.
Intel 6th Gen. Core i3 indbygget i3-6100U / i5 (option).
1 x 260Pin SO-DIMM DDR4 op til 16GB 2133MHz.
Flad frontpanel møder IP66
trykstøbning af aluminium Chassis Fanless design
DC 9 ~ 36V vidtrækkende Power Input
OPTION: CAN Bus, UPS-batteri, 4 xUSB
