12 x relay outputs, COM N.O. NO contact to 30VDC / 5A, 250VAC / 5A, M485 bus, 10 - 30VDC
Product code: M485-REL12-I
M485-REL12-I provides 12 power relay output channels. There are options for configuring power-on and safe values. 4 kV ESD protection and 3750 VDC intra-module isolation are also provided to enhance the noise protection capabilities in industrial environment. The “D” versions provide 12 LED indicators that can be used to monitor the status of the relay output channels. The M485-REL12-I series are the ideal solution for high power applications.
M485-REL12-I
1 Item
Data sheet
- Forsyning
- 10 - 30 VDC, 0,8 W via klemrække
- Udgange
- 12 type A (slutte) relæer
- Kontaktdata
- AC: 250 V / 5 A, DC: 30 V / 5 A Lukketid: 10 ms, åbnetid: 5 ms
12 connect relays (COM N, O.)
RS485 communications bus
