4 x analog output, 0 - +/- 10V and 0 - 20mA, 14bit. 5 x digital input with DRY contact to GND. RS485 bus. 10 - 30vdc.

Product code: M485-DA4DI5-1

RS485 module with volt / mA output. Digital input
4 x analog output - 0 - +/- 10V and 0-20mA
Resolution: 14bit
5 x Digital input - Active high on contact for frame
RS485 Bus - Module is Slave
Format: (N, 8, 1) (N, 8, 2) (E, 8, 1) (O, 8, 1)
Baud Rate: 1200 ~ 115200 bps
Supply: 10 ~ 30 VDC

  • Add to Comparison Remove from Comparison
    • 3,099.00 DKK
    Tax excluded
    Last items in stock
    Quantity

    M485-DA4DI5-I is a 14-bit 4-channel analog output module that provides power and voltage outputs. There are opportunities for choosing start-up values ​​and Safe-Value (safe values). It has 3000 VDC insulation within the module. With 5-channel digital inputs and 4 kV ESD protection on each terminal.

    M485-DA4DI5-1
