I / O module with 12 DI and 8 DO Web-based. Moxa ioLogik E2210
Product code: ETHIO12I8O-M
Automatic control of the output channels, depending on the input conditions
Digital and analog input and temperature sensors monitoring
Controls the digital and analogue outputs and relay contacts
simple configuration, does not require any programming knowledge
refine by max. 16 rules with up to 3 input and output status
definition of status messages (TCP / UDP, SNMP trap or e-mail)
peer-to-peer mode for simple transmission of I / O signals via Ethernet
Supports active OPC for communication with SCADA systems
Ethernet connection (RJ45 10/100 Mbps) and RS485 interface
Power supply: 12-36 VDC
ETHIO12I8O-M
Data sheet
- Driftstemperatur
- -40 - 75°
MOXA ioLogik E2210
Ethernet Micro RTU Controller
1 x 10/100 Mbps, RJ45
1.5 KV magnetic isolation
Modbus / TCP, TCP / IP, UDP, DHCP, Bootp, SNMP ( MIB for I / O and Network), HTTP, CGI, SNTP
RS-485-2w Data +, Data-, GND
15 KV ESD
12 x digital input - source type
Digital output: 0 to GND
Logic 1 open
Wet Contact: Logic 0 0:02 3 VDC
Logic 1 10:02 30 VDC (DI COM two DI)
8 x Open Collector sink type: 36 VDC / 200 mA
Power supply: 12-36 VDC
