8 channel frequency counter, max. 500kHz via USB. Pulse Count Up / Down or Phase A / B. Powered from USB port
Product code: USB-COUNT
USB Count is a USB device with 8-channel for frequency and telescopes or 4-channel to up / down, direction / pulse and A / B phase counters.
is For industrial control and manufacturing test applications, such as factory automation or built-in machine control. Plug Play, so you do not need to open your computer to install cards, just connect the module and then download or set the data.
Because of another USB function known as "hot-swapping" needs not even to close down and restart the system to connect or remove a peripherals.
USB I / O The tool can help users configure and test USB count quickly and easily without programming:
In addition, We also an API library and demos so that users can develop own USB application with different application development tools (VB / C ++ / C # .NET / VB.NET). Therefore, USB Count is the perfect way to add measurement and Control functions for any USB compatible computer.
USB-COUNT
Data sheet
- Forsyning
- Via USB porten
- Stik
- USB type B og skrueterminaler
- Montering
- DIN-skinne
- Isolation
- 2500 VDC
- Software
- USB driver til Windows 2000,XP, Win7 og Win8
- Dimensioner
- 102 x 33 x 107 mm
- Indgang
- Ikke isoleret Logisk 0: 0 – 0,8 V, Logisk 1: 2 – 5 V. Isoleret Logisk 0: 0 – 1 V Logisk 1: 4,5 – 30 V
Versatile frequency counter, pulse counter via the USB port
Power supplied from the USB port
Total 8 inputs, of which:
4 channels for up / down, dir / pulse, Phase AB
8 channels for count- Up and frequency counter
32 bit resolution
Max. 500kHz (non-isolated)
input voltage: 0 - + 30V
USB 2.0
DIN mount
Dim: 107 x 102 x 33 mm
Operating temperature: -25 - +75°C
