L-CON Controller with 7 x Temperature sensor input, 2/3 wire Pt100, Pt1000, Ni120, CU100, Cu1000, 1 x RJ45 Ethernet, PoE

WISE (Web Inside, Smart Engine) is a product line developed by ICP DAS that functions as control units for use in remote logic control and monitoring in various industrial applications. WISE offers a user-friendly and intuitive web site interface that allows users to implement IF-THEN-ELSE control logic on controllers just a few clicks away; no programming is required. With its powerful and user-friendly features minimizes the learning curve, shorten time to market and reduces the effort and costs dramatically for system development.

L-CON7RTD follows IEEE 802.3af-compliant (classification, Class 1) Power over Ethernet (PoE) specification . It allows to receive power from the PoE-enabled network via Ethernet pairs (Category 5 Ethernet cable). This feature provides greater flexibility and higher efficiency, which simplifies system design, saves space, reduces cables and eliminates the need for dedicated electrical outlets. Meanwhile, L-CON7RTD in case of an environment without PoE still be able to receive power from the auxiliary power sources like AC adapters or battery, etc.

This module L-CON7RTD supports Modbus / TCP protocol to make seamless integration with SCADA software available. It has 16-bit, 7-channel RTD inputs. Each channel has allowed to set up an individual interval that supports the 3-wire RTD lead resistance elimination ledningsdetektion and open to the RTD measurement.
