Composite video (BNC) over optical Multi Mode fiber cable (simplex), up to 2 km. Set is transmitter and receiver.

Product code: BOOST-VIDEO-STM

Composite Video, BNC, over multimode fiber cable
set consists of transmitter and receiver module
only single fiber (simplex) for digital transfer
Please use Normal Duplex Fiber cable, where one fiber does not Used
Up to 2km between transmitter and receiver
stand-alone or rack mounting

  • Add to Comparison Remove from Comparison
    • 2,640.00 DKK
    Tax excluded
    Physically in stock
    Quantity

    Number of Channels: 1 Channel Video
    Video Input / Output Impedance: BNC 75Ω
    Video Input / Output Compatibility: PAL, NTSC, SECAM
    Video Input / Output Voltage: 1 , 0 Voltpp
    Bandwidth: 6.5MHz
    Bit Resolution: 8-bit Digital Transmission - Signal to Noise Ratio (SNR): 67 dB
    Connectors:
    Video: 75 Ohm BNC (Gold Center) Pin)
    Optical: ST
    Stand-Alone Power: Screw Terminal Block
    Rack Power: AC Cord

    Power Requirements: 5VDC/2A
    Power Adapter: 100V ~ 240VAC
    Power Consumption: 3W
    Stand-Alone Dimensions: 95mm × 70mm × 25mm

    Operating Temperature: -40°C ~ +75°C
    Storage Temperature: -40°C ~ +85°C - Relative Humidity: 0% ~ 95% (non-condensing)
    MTBF: 100,000 hours
