Internal USB to RS232 converter card
Product code: CNV-USB-RS232INT
With CNV-USB2RS232INT, newer PCs can get 2 x RS232 ports without having external boxes connected. The card is connected to an internal USB connector (USB cable not included) or directly to the motherboard using the supplied cable. 5 VDC can be supplied from the serial port for e.g. POS equipment. The voltage is activated / deactivated with jumpers on the card.
CNV-USB-RS232INT
7 Items
Data sheet
- Stik
- 1 x DB9 han og 1 x RJ45 hun (RJ45 til DB9 kabel medfølger)
- Porte
- 2 x RS232
- Maks. hastighed
- 230 Kbit/sekund
- Drivere
- Windows 2000, XP, 2003, Vista, Win7 og Win8
- USB
- Tilsluttes enten USB A hunstik eller pins på kortet (medfølgende kabel forbindes til 4 pins på kortet og 4 USB-pins på bundkortet)
- Strømforsyning
- Forsynes af 4-pins Molex stik
- UART
- 16550
- Høj/lav bagplade
- Begge bagplader medfølger
- I/O
- Plug & Play
Two 16550 High performance UART (RS232) serial channels
Occupies one PCI or PCIe bus slot
Low Profile PCI Form Factor
Includes Low Profile PCI & Regular size PCI two brackets
Both USB A type and USB pin header connector on board to host connection
One RS232 DB9M and one RS232 10pin RJ45 serial ports on board
Includes one 10pin RJ45 – DB9M Bridge cable for 2nd DB9M port
5VDC Power output from each DB9M Port for POS device use application
2 Jumpers Individually enable / disable 5VDC output for each DM9M Port
On Board Molex mini 4Pin Power connector for sufficient DB9M 5V bus power from PC power supply
Supports 32bit/64bit Windows 7, Vista, XP, 2000, ME, 98SE
