19 "TFT monitor with 350-nits LCD, with electricity without touch, dust and leakproof IP66, Dual AC / DC inputs,

Product code: MON19-TFT-MD

19 "TFT metal monitor LED backlight, IP66
1280 x 1024
350 nits, 1000: 1, 5: 4
Response time: 5ms
viewing angle: 170 ° / 160 °
3 x BNC
2 x DVI-I (29-pin DVI-D female)
1 x VGA (15-pin D-sub femlae)
1 x RS232 / 422/485 (software selectable terminal blocks)
100 to 240 VAC, 24 VDC (18 to 30 V)
-15 to 55 ° C (5 to 131 ° F)
weight: 9,700 g
483 x 444 x 82 mm
Panel mounting
RoHS, CRoHS, WEEE
Optional: RS-232: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
Optional: RS-422: Tx +, Tx- , Rx +, Rx-, GND
Optional: RS-485-2w: Data +, Data, GND
Optional: RS-485-4w: Tx +, Tx-, Rx +, Rx-, GND

  • Add to Comparison Remove from Comparison
    • 34,855.00 DKK
    Tax excluded
    On the way in
    Quantity

    MON19-TFT-MD

    Data sheet

    Weight
    9,700 g
    Forsyning
    100 to 240 VAC, 24 VDC (18 to 30 V)
    Porte
    1 x RS232/422/485 (software valgt terminal blok)
    Pixels
    1280 x 1024
    Dimensioner
    483 x 444 x 82 mm
    I/O
    3 x BNC, 2 x DVI-I, 1 x VGA
    Antal farver
    16.7M (8-bit/color)
    Kontrast
    1000:1, 350 nits, 5:4
    Betragtningsvinkel
    170°/160°
    Certifications
    EMC EN 55032/24
