Fanless Embedded PC Gen. 13/12 LGA1700, 2x2.5Gbe, 3xDP, 1xVGA, 9~48V DC, -40°C ~ 70°C, 9xUSB3.2, 6xRS232/422/485 RAID

Product code: EPC-GEN13-9U6S2E3DP

Intel Gen. 13/12 LGA 1700 35W Processor Core/Pentium/Celeron
Intel R680E
TPM 2.0
Max. 64GB RAM
Quad display: 1xVGA (1920x1200), 3xDP 4096x2160), (3xHDMI 4096x2160 on special inquiry)
9 x USB3.2 (Gen.2)
6 x RS232/422/485
2 x 2.5GbE Intel i226-IT
4 x GbE Intel i350-AM4 or 4 x GbE POE+ (Expansion modul on request)
Audio line in/out
8 x Isolated DI and 8 Isolated DO (2 x 9-pin Terminal block)
2x 2.5" Sata III
2 x M.2
2 x SIM socket
-40°C ~ 70°C
240x200x88mm
9-48V DC Input with Ignition Control
CE/FCC Class A
OS Support: Windows 10 IoT, Windows 11 (IoT/Professional), Linux

  • Add to Comparison Remove from Comparison

    • Call For Price
    0.00 DKK
    Tax excluded
    On the way in
    Quantity

    EPC-GEN13-9U6S2E3DP

    Data sheet

    Weight
    3.9 kg
    CPU
    13th/12th Gen Intel® Core™/Pentium®/Celeron® 35W LGA 1700 Processors,
    Driftstemperatur
    AT
    Chipset
    Intel® R680E
    BIOS
    AMI 256 Mbit SPI Flash
    OS SUPPORT
    Windows 10 IoT, Windows 11 (IoT/Professional), Linux
    Antenne
    4x Antenna Hole
    Lyd
    1x Line-out, 1x Mic-in
    Montering
    Wall Mount (Additional Mounting Kit)
    Luftfugtighed
    10% ~ 90% (non-condensing)
    Ethernet
    2 x 2.5GbE Intel® i226-IT, RJ45, (4 x GbE Intel® i350-AM4 or 4 x PoE+ Intel® i350-AM4 optional IO)
    USB
    9 x USB 3.2 (Gen2)
    Digital I/O
    8 x Isolated DI and 8 x Isolated DO, 2 x 9-pin Terminal Block
    Grafik
    3 x DP, 1 x VGA (3xHDMI optional contact sales)
    Chok/Vibration
    Vibration 5Grms, 5-500Hz, 0.5hr/axis Shock 50G, Half-sine 11ms
    RAID niveau
    RAID 0/1/5/10
    SIM kort
    2 x Mini-SIM Holder
    Indgangsspænding
    9-48V DC Input with Ignition Control,
    mPCIe
    1 x Full-Size Mini-PCIe (PCIe, USB 2.0 and SIM)
    TPM
    TPM 2.0
    M.2
    1 x M.2 M-Key1 2280 (SATA) 1 x M.2 M-Key2 2280 (NVMe x4 and SATA)
    Other
    with Ignition Control,
    Protection
    Over Voltage Protection (OVP) up to 52V Over Current Protection (OCP) up to 20A Reverser Voltage Protection (RVP) up to -48V
    Dimension
    240 x 200 x 88mm, (
    Certification
    CE/FCC Class A
    Material
    Aluminum & SECC
    Serial Porte
    6 x RS232/422/485
    RAM
    2 x 262-PIN SO-DIMM Dual Channel DDR5 4800/5600 (ECC and Unbuffered) Max. 64GB
    Display
    Multi Display 4, VGA, 3xDP
    Expansion
    M.2
