USB to RS232 / RS422 / RS485 High-speed Convert up to 921.6 Kbps, 3KV DC isolation
Product code: M485-USB-I-U
Interface: USB 1.1 / 2.0 / 3.0
Serial interface:
RS-232: RS-232, RS-422 and RS-485 cannot be used at the same time
• TxD, RxD , GND
• TxD +, TxD-, RxD +, RxD-
• Data +, Data-
RS-422/485 transmission distance: Max. 1,200 m at 9.6 kbps; Max. 400 m at 115.2 kbps
(Belden 9841 2P twisted pair cable (if other cables were used, the transmission distance can be changed)
Speed: 300 ~ 921.6 kbps
Connector: RS-232 / 422/485: removable 10-pin terminal block for USB: Type B
Cable attached: CA-USB18 (1.8 m cable) x 1
LED indicator: Power - Input: +5 VDC via USB < br> Power consumption: 0.5 W
Plastic enclosure: fire retardant materials (UL94-V0 level)
Dimensions: (W x H x D) 72 mm x 115 mm x 35 mm
Installation: DIN rail Mounting
Operating Temperature: -25 ° C ~ +75 ° C
Humidity: 10 ~ 90% RF
M485-USB-I-U
3 Items
Data sheet
- Forsyning
- +5 VDC via USB
- Kabinet
- Brandhæmmende materialer (UL94-V0 level)
- Driftstemperatur
- -25 °C ~ +75 °C
- Interface
- USB 1.1/2.0/3.0
- Stik
- USB type B og RS232/422/485
- Strømforbrug
- 0.5 W
- Afstand
- RS-422/485 Transmission afstand : Max. 1,200 m at 9.6 kbps; Max. 400 m at 115.2 kbps
- Luftfugtighed
- 10 ~ 90% RH
- Isolation
- 3000V DC
- Dimensioner
- (W x H x D) 72 mm x 115 mm x 35 mm
- Installation
- DIN-Rail montering
High-speed USB to RS232/422/485 converter
Supports USB 1.2 / 2.0 / 3.0
3000V DC insulation on RS232 / 422/485
Transmission speed - up to 921.6 kbps
RS232 / 422/485 cannot be used simultaneously
Supplied via USB port
Automatic RS485 Direction Control
Temperature range: -25 ° C - + 75 ° C
DIN rail mounting
Windows 98/ME/2000/XP/Vista (32/64-bit)
Windows 7 / 8.1 / 10 (32/64-bit)
Win 2012
Linux
