RS232 to Multi Mode fiber converter 50/125 or 62.5 / 125my, ST connector. DB9 he, up to 1.7km

Product code: CNV232FIBER-DB9

max baud rate 115kb / s for 56kb / s for signal RI
Up to 1.7km at 62.5um fiber cable.
Fiber Optic line multimode, 820nm
Transmitting: RxD , TxD, DTR, DSR, RTS, CTS, DCD, RI or 5x RxD, TxD
RS232 signal including DCE / DTE
Time multiplex, full duplex
RS232 DB9 male
Plug fiber ST
overvoltage (soft) protection - supply 600W / 1ms
polarity protected with diodes on DC input
optical indication (LED) red - PWR
Yellow - INPUT signal
Green - OUTPUT signal
Supply voltage 10-30VDC or 9 - 24VAC
power consumption max. 2W
Dimensions: 76 x 55 x 115 mm

  • Add to Comparison Remove from Comparison
    • 1,155.00 DKK
    Tax excluded
    Last items in stock
    Quantity

    Hastighed: Op til 115,2 Kbit/s

     Afstand: Op til 1,7 km

     Dataoverførsel: Tx, Rx (Software handshake)

     Fibertype: Multimode 62,5/125 um

     Bølgelængde: 820 nm

     Forsyning: 10 - 30 VDC eller 9 - 24 VAC, 1,1 W. Strømforsynes gennem skrueterminaler

     Stik: RS232: DB9 han eller skrueterminaler, lysleder: ST hun

    CNV232FIBER-DB9
    1 Item
