RS232 to RS422 / 485 converter. Can be powered from COM port control signals

Product code: CNV232-485PW+

With CNV232-485PW + you get an RS485 or RS422 port on the PC
Selecting RS422 or RS485 with DIL switches on the device
Super compact with DB9 female and screw terminals
Can be powered by external voltage from 9 - 12VDC / 500mA
Operating temperature: -40 - + 85 ° C

  • Add to Comparison Remove from Comparison
    • 906.00 DKK
    Tax excluded
    Physically in stock
    Quantity

    Type: RS232 'RS422 / RS485 converter
    Speed: Up to 921.6 kbit / s
    Distance: Up to 1.2 km on RS422 / 485 s in it and up to 15 m in RS232 since
    Supply: Supplied by RS232 port or 9 - 12VDC
    Connectors: RS232: DB9F, RS485: Screw Terminal
    switch to select RS422 or RS485 well as local echo on or off by RS485
    signals: RS232 : TXD, RXD, RTS, DTR, GND
    signals: RS422: TXD +, TxD-, RXD +, RXD-
    signals: RS485: TRXD +, TRXD-

    CNV232-485PW+
    9 Items

    Data sheet

    Forsyning
    Forsynes af RS232 porten
