USB to 1 x RS232 / RS422 / RS485 Converter. 300 - 115.2Kbit. Signal is +/-11volt. Galvanically isolated on com out

Product code: M485-USB-I

Serial for USB converter with 1 x RS232 / 422/485-port
Respect +/- 11volt data signals
Galvanically isolated on RSXXX Exit
Self-Tuner Baud Rate
Automatic Direction Control
Powered from the USB port
USB connector: Type B
COM Port: Terminal Block

  • Add to Comparison Remove from Comparison
    • 1,311.00 DKK
    Tax excluded
    Physically in stock
    Quantity

    M485 USB-I is a cost-effective module for transferring serial data via USB. It allows you to connect your serial devices to systems that use a USB interface. Connecting the M485 USB-I to a PC you get an RS-232 / 422/485 port. Contains a "self-tuner" chip that automatically sets baud rate and data format for the RS-485 network. Gets its power from the USB port and does not need any power adapter.

    M485-USB-I
    10 Items

    Data sheet

    Forsyning
    Forsynes via USB porten forbrug 0,65 W
    Stik
    USB Type B hun og RS232/422/485 Skrueterminaler
    Afstand
    Op til 1,2 km med RS422/485
    Isolation
    3000 VDC
    Software
    Windows 98/ME/2000/XP/Vista (32/64-bit)/7 (32/64-bit)/8 (32/64-bit)/8.1 (32/64-bit)/10 (32/64-bit)/2012/Linux
    Data
    Fra 300 bit/sek. til 115,2 kbit/sek.
